Tech & Features
ALUXX SLR Aluminum Technology
This superlight Pro level aluminum material is made predominantly from 6011 alloy and delivers the highest strength-to-weight ratio of any Giant aluminum frameset. State-of-the-art microscopic grain manipulation and advanced butting allows for 20 percent thinner and lighter tube shapes than ALUXX SL framesets.
Tubeless System
Fewer flat tires. Greater traction. Less rolling resistance and a smoother, faster ride. Giant’s Tubeless System makes it easier than ever to experience all these benefits.
OverDrive
Giant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
Sizing Guide
Sizing to be used as a reference only and based on rider's height. Please check with us to determine the correct size.
- S: 163cm - 172cm
- M: 171cm - 180cm
- L: 179cm - 188cm
- XL: 187cm - 198cm
Specs
| Sizes | S, M, L, XL |
| Colours | Deep Lake, Abyss Black |
| Frame | ALUXX SLR-grade Aluminum, 12x148mm thru-axle |
| Fork | Giant Crest 34 RRL, 100mm, 15x110, remote lockout |
| Shock | N/A |
| Handlebar | Giant Connect XC, 740x31.8mm |
| Grips | Giant Sole-O |
| Stem | Giant Contact S:60mm, M:70mm, L:80mm, XL:90mm |
| Seatpost | Giant Contact Switch Core dropper, remote S: 100mm travel / 30.9 x 350mm, M: 100mm travel / 30.9 x 350mm, L: 120mm travel / 30.9 x 400mm |
| Saddle | Giant ErgoContact Trail |
| Shifters | Shimano SLX M-7100, 1x12 |
| Front Derailleur | N/A |
| Rear Derailleur | Shimano SLX M7100 |
| Brakes | Shimano BR-MT500, hydraulic, Shimano RT-10 rotors [F]180mm, [R]160mm |
| Brake Levers | Shimano BR-MT501 |
| Cassette | Shimano SLX, 10x51 |
| Chain | KMC X-12 |
| Crankset | Shimano SLX, 32t S:170mm, M:175mm, L:175mm, XL:175mm |
| Bottom Bracket | Shimano, press fit |
| Rims | Giant XCT 29, 25mm inner width |
| Hubs | Shimano C500, sealed |
| Spokes | stainless |
| Tires | Maxxis Recon Race 29x2.4, foldable, TLR, EXO, tubeless |
| Extras | tubeless prepared, 2.4" max tire size, 36t max chainring size |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
1119019124 - Abyss Black
